LUMISTAR INFRARED IMAGING NEWS

By Lumistar's Chief Scientist

April 15, 2013

Thermal Quasi-Reflectography For Art Conservation

(a) Color Photo; (b) Near Infrared -NIR; (c) Mid-Wave Thermal Infrared; Note: helmet detail in photo ‘c’

In recent times, art restorers have employed lasers and other sophisticated imaging techniques by other infrared techniques or Ultraviolet and X-ray to reveal details not present to the naked eye. Over time wall murals are re-touched, many times painting over original details unrecoverable by past imaging tools.  Now a team of Italian researchers from the University of L’Aquila, the University of Verona, and Italy’s National Institute of Optics in Florence, have developed the latest imaging tool that can bring back these features for future restoration, and may even give more details about pigments used long ago.

This technique known as Thermal Quasi-Reflectography (TQR), takes advantage of reflected infrared light from the mid-infrared part of the spectrum (3-5 micrometers in wavelength). Why specifically the mid-infrared portion of the spectrum?  Because certain materials shine more brightly in one wavelength than in others.  At normal room temperature, paintings typically emit more invisible light in the longer infrared wavelengths than they do in the mid-infrared. These researchers came up with the idea of flooding the works of art with these normally scant (1.1%) mid-infrared wavelengths (using halogen lights a great sources of mid-IR) to see what detail reflects back with an infrared camera. Unlike traditional thermal imaging techniques reading the heat differences reflected represented by individual pigments, or the less detailed reflection of light in the Near Infrared (NIR), the TQR system reveals new details of great works of art.

The researchers were careful the halogen lams were place far away enough not to produce heat on the art which would defeat the process creating longer wavelengths.  “For mural paintings the use of the mid-infrared regions reveals crucial details,” said Daffara. “This makes TQR a promising tool for the investigation of these artworks.”

More:  http://www.osa.org/en-us/art-and-optics-converge-frescos/
